Description

Control terminal

Dimension (L * W * H)

300 * 190* 43 ( mm )

System

Android

Network Mode
 4G, compatible with 2G/3G

Display

10.1 inches,1280×800 pixels,

Waterproof Level

IP65

Power Interface

                                              10V ~ 30V

InterfaceRadar × 1,4G × 1, GNSS × 2,
Base Station × 1

Electric Steering Wheel

Size

 370*370*123 mm

waterproof Level

IP66

Power Supply
                                 12V/24V DC



GNSS Antenna

Size

152*63 mm

Support Source

 GPSL1/L2,GLONASSL1/L2,BDSB1/B2/B3

Waterproof Level

 IP67

Operating Temperature Range
 -20°C ~ 70°C

IMU

Accelerometer

 0.5 mg

Gravity Sensor

 0.1°/s

Electronic Compass

 0.2°

Power Interface

 5 V

Angle Sensor

Operating Temperature Range

 -40° C ～ 85° C

Waterproof Level

 IP67
